Wall mounted battery pack
51.2V150Ah wall mounted battery pack
Nominal Voltage/Nominal Capacity: 51.2V/150Ah wall-mounted with 7.68Kwh energy
Customization can be made according to requirements:
32V150Ah wall mounted battery pack
32V184Ah wall mounted battery pack
48V50Ah wall mounted battery pack
48V100Ah wall mounted battery pack
48V150Ah wall mounted battery pack
48V184Ah wall mounted battery pack
48V280Ah wall mounted battery pack
51.2V50Ah wall mounted battery pack
51.2V100Ah wall mounted battery pack
51.2V150Ah wall mounted battery pack
51.2V184Ah wall mounted battery pack
51.2V280Ah wall mounted battery pack
Product Parameters
| Technical Specification | |
|---|---|
| Rated power: |
10KW |
| Battery energy: | 7740W |
| Cell type: | Lithium iron phosphate |
| Cell composition method: | 150A large monomer/16S1P |
| Nominal capacity: | 150Ah |
| Nominal voltage: | 48V |
| Circular Fang Ming: | 2000 times |
| Working voltage range: | 42V-58.4V |
| Standard charging: | 58.4V30A |
| Maximum charging current: | 80A |
| Continuous discharge current: | 100A |
| Peak discharge current: | 300A (0.3mS) |
| Packaging method: | 1 outer (pearl cotton 1 set (2PCS) |
| Gross weight: | 66.1kg |
| Outer box size: | 616 * 590 * 260MM |
| Packing list: | 1 instruction manual, 1 brochure, 1 iron bracket, 1 communication box, 1 network cable, 4 expansion screws, 1 red/black silicone cable each, 1 battery pack (size: 52 * 49 * 16CM) |
| Weight: | 57.6kg) |
