Stacked battery pack
5.12KWH Stacked battery pack
Inverter parameters:
Output power: 5600W
Peak power: 11000VA
Output voltage waveform: sine wave
Frequency: 50/60Hz(Auto detect ）
Output voltage: 230V±5%
Inverter efficiency: >92%
PV working voltage range: 100V~500V
PV input power: 6000W
PV maximum charging current: 100A
Municipal power charging power: 3600WMAX
Inverter module length, width/weight: 537*390*166mm /36Kg
Product Parameters
| Technical Specification | |
|---|---|
| Battery energy: | 5.12KWH |
| Nominal voltage: | 51.2V |
| Nominal capacity: | 100Ah |
| Working voltage range: | 40~58.4V |
| Standard charging voltage: | 58.4V |
| Discharge cut-off voltage: | 40V |
| Standard charging current: | 50A |
| Maximum charging current: | 100A |
| Maximum discharge current: | 120A |
| Peak discharge current: | 150A@30s |
| Cell type: | Lithium iron phosphate |
| Composition of battery cells: | 16S1P |
| Cycle life: | 6000+second |
| Charging temperature | 0~60 ° C |
| Discharge temperature | -20~60 ° C |
| Storage temperature | 10-45 ° |
